2N IP One, 1920 x 1440 pixels, 4:3, CMOS, 25.4 / 2.7 mm (1 / 2.7"), 30 fps, 0.3 lx
£1,321.25
Description
2N IP One. Display resolution: 1920 x 1440 pixels, Display aspect ratio: 4:3. Sensor type: CMOS, Optical sensor size: 25.4 / 2.7 mm (1 / 2.7"), Maximum frame rate: 30 fps. Speaker power: 3 W, Voice codecs: G.711, G.722, G.729. Product colour: Black, International Protection (IP) code: IP66, IK code: IK08. Ethernet interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X)Specifications
| Technical details | |
|---|---|
| International Protection (IP) code | IP66 |
| Voice codecs | G.711, G.722, G.729 |
| Built-in speaker(s) | Yes |
| Built-in microphone | Yes |
| IK code | IK08 |
| Video codecs | H.264, MJPEG, Zipstream |
| Number of buttons | 1 buttons |
| Backlight buttons | Yes |
| Speaker power | 3 W |
| Number of speakers | 1 |
| Speakerphone | Yes |
| Maximum number of cameras supported | 1 |
| Connectivity technology | Wired & Wireless |
| Warranty period | 5 year(s) |
| Display | |
| Display resolution | 1920 x 1440 pixels |
| Display aspect ratio | 4:3 |
| Wide Dynamic Range (WDR) | Yes |
| Camera | |
| Viewing angle, vertical | 116° |
| Viewing angle, horizontal | 156° |
| Minimum illumination | 0.3 lx |
| Maximum frame rate | 30 fps |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
| Fixed focal length | 1.93 mm |
| Night vision | |
| Night vision | Yes |
| Audio | |
| Voice codecs | G.711, G.722, G.729 |
| Built-in speaker(s) | Yes |
| Speaker power | 3 W |
| Number of speakers | 1 |
| Design | |
| International Protection (IP) code | IP66 |
| Proper use | Outdoor |
| Smartphone support | Yes |
| IK code | IK08 |
| Product colour | Black |
| Placement supported | Vertical |
| Housing material | Aluminium |
| Control type | Buttons |
| Vandal-proof | Yes |
| Network | |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Cabling technology | 10/100Base-T(X) |
| Power over Ethernet (PoE) | Yes |
| Supported network protocols | RTP, RTSP, SRTP |
| Networking standards | IEEE 802.3af |
| Power | |
| Power consumption | 600 mA |
| AC adapter input voltage | 20 V |
| AC adapter output voltage | 12 V |
| AC adapter output current | 2 A |
| Outdoor unit power type | DC/PoE |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 95% |
| Weight & dimensions | |
| Width | 78 mm |
| Depth | 53 mm |
| Height | 172 mm |
| Weight | 355 g |
| Packaging data | |
| Outdoor unit included | Yes |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
