Axis 01710-001 security camera Dome IP security camera Indoor & outdoor 2592 x 1944 pixels Wall
£2,232.50
4x1/2.5" CMOS, 2592x1944px, 4x5MP, 20 fps, IP66, IK10, PoE, 23W

Key Features

  • 360° camera with one-click PTZ control; 4 x 5 MP sensors, total 20 MP resolution; Directional audio detection included; Exchangeable and tiltable lenses; Requires an AXIS Q61 Series or AXIS Q63 Series camera

Description

With four 5 MP sensors, AXIS Q6100-E provides a complete 360° overview with great image usability day and night. Designed for use with any AXIS Q61 Series or AXIS Q63 Series camera, it enables one-click PTZ control and autopilot for automatic PTZ tracking within the viewing areas. Directional audio detection triggered by audio incidents redirects the PTZ camera to the audio source. Each sensor has exchangeable lenses with autofocus for maximum flexibility and accurate configuration. AXIS Camera Heater Power Supply is required when AXIS Q6315-LE is used.

Specifications

Performance
Preset points Yes
Infrared (IR) cut-off filter Yes
Type IP security camera
Connectivity technology Wired
PTZ control Yes
Placement supported Indoor & outdoor
Wide Dynamic Range (WDR) Yes
Certification EAC, EN 55032 Class A, EN 55035, EN 50121-4, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KN35, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN/UL 60950-22, CAN/CSA-C22.2 No. 60950-22, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9), NIST SP500-267
Design
IK code IK10
Form factor Dome
Product colour Black, White
Mounting type Wall
International Protection (IP) code IP66
Housing material Aluminium, Polycarbonate (PC)
Camera
Minimum illumination 0.003 lx
Field of view (FOV) angle 360°
Camera shutter speed 1/32500 - 1/20 s
Lens viewing angle, vertical 84°
Progressive scan Yes
Image sensor
Sensor type CMOS
Progressive scan Yes
Optical sensor size 25.4 / 2.5 mm (1 / 2.5")
Number of sensors 4
Lens system
Maximum aperture number 2
Auto focus Yes
Fixed focal length 2.8 mm
Video
Image quality adjustment Brightness, Contrast, Saturation, Sharpness
Text caption overlay Yes
Privacy masking Yes
Bit rate control Variable Bit Rate (VBR)
Video compression formats AVC, H.264, H.265, HEVC, MPEG4
Maximum resolution 2592 x 1944 pixels
Supported graphics resolutions 320 x 240, 2592 x 1944
Frame rate 20 fps
Video streaming Yes
Total megapixels 20 MP
Audio
Audio detection Yes
Network
Ethernet interface type Fast Ethernet, Gigabit Ethernet
Networking standards IEEE 802.1x
Streaming method Multicast
Ethernet LAN Yes
Supported network protocols IPv4, IPv6 USGv6, HTTP, HTTPS , HTTP/2, SSL/TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SRTP, TCP, UDP, IGMP, RTCP, ICMP, DHCPv4/v6, ARP, SOCKS, SSH, NTCIP, LLDP, MQTT v3.1.1, Syslog
Storage
Card reader integrated Yes
Compatible memory cards SD, SDHC, SDXC
Flash memory 512 MB
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Connectivity technology Wired
Security
Alert notification type E-mail
Video motion detection Yes
Active tampering alarm Yes
Power
Power source type PoE
Power consumption (max) 23 W
Power consumption (Power over Ethernet (PoE)) 9 W
Certificates
Certification EAC, EN 55032 Class A, EN 55035, EN 50121-4, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class A, KN35, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN/UL 60950-22, CAN/CSA-C22.2 No. 60950-22, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X, NEMA TS 2 (2.2.7-2.2.9), NIST SP500-267
Operational conditions
Operating temperature (T-T) -50 - 50 °C
Storage temperature (T-T) -40 - 65 °C
Operating relative humidity (H-H) 10 - 100%
Storage relative humidity (H-H) 5 - 95%
Weight & dimensions
Width 361 mm
Depth 361 mm
Height 192 mm
Weight 4 kg
Other features
Video compression formats AVC, H.264, H.265, HEVC, MPEG4
Logistics data
Harmonized System (HS) code 85258900
