USB 3.1 Type C to HDMI 2.0 UHD 4K 60HZ Active Adapter
Supports up to 4K UHD Resolution at 60Hz.
The USB 3.1 Type C to HDMI™ 2.0 UHD 4K 60Hz Active Adapter supports UHD resolutions of up to 4K @ 60Hz for a clear, sharp picture. The support for 60 frames per second provides exceptionally smooth video. Use the adapter to play games, view video or browse the internet from your USB 3.1 Type-C enabled device on a (Ultra) high-resolution monitor or TV. Supporting up to 8 channels of audio, the adapter provides high-definition digital audio and video.
Compatible with all Operating Systems
The USB 3.1 Type C to HDMI™ 2.0 UHD 4K 60Hz Active Adapter supports all USB 3.1 Type-C devices with DisplayPort™ ALT mode and operating systems, including Apple OS X, Windows 8.1 and 10 and Google Chrome OS.
Please refer to your device's user manual to confirm the specification and functionality of the USB-C port.
£36.25
Key Features
- Connect 4K Screen with HDMI 2.0 input to Notebook with USB C / Thunderbolt 3 output
- Supports resolutions up to 3840x2160 at 60Hz
- Fully compliant ot HDCP 1.3 / 2.2 and HDMI 2.0 specifications
Description
The Club 3D CAC-2504 is an Active HDMI™ signal converter. The USB 3.1 Type C to HDMI™ 2.0 UHD 4K 60Hz Active Adapter is the easiest solution for connecting your USB 3.1 Type C source device featuring DisplayPort™ Alternate Mode to an HDMI™ 2.0 enabled UHD Monitor, Television or Projector. The HDMI™ adapter is compact and highly portable. Powered by the USB-C port, the adapter requires no external power and is ideal for use with notebooks and Ultrabooks.Supports up to 4K UHD Resolution at 60Hz.
The USB 3.1 Type C to HDMI™ 2.0 UHD 4K 60Hz Active Adapter supports UHD resolutions of up to 4K @ 60Hz for a clear, sharp picture. The support for 60 frames per second provides exceptionally smooth video. Use the adapter to play games, view video or browse the internet from your USB 3.1 Type-C enabled device on a (Ultra) high-resolution monitor or TV. Supporting up to 8 channels of audio, the adapter provides high-definition digital audio and video.
Compatible with all Operating Systems
The USB 3.1 Type C to HDMI™ 2.0 UHD 4K 60Hz Active Adapter supports all USB 3.1 Type-C devices with DisplayPort™ ALT mode and operating systems, including Apple OS X, Windows 8.1 and 10 and Google Chrome OS.
Please refer to your device's user manual to confirm the specification and functionality of the USB-C port.
Specifications
| Features | |
|---|---|
| Country of origin | China |
| HDMI version | 2.0b |
| Product colour | Black |
| Cable length | 0.15 m |
| Connector 1 | USB Type-C |
| Connector 2 | HDMI Type A (Standard) |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| Connector contacts plating | Copper |
| Data transfer rate | 18 Gbit/s |
| Maximum resolution | 3840 x 2160 pixels |
| Supported graphics resolutions | 3840 x 2160 |
| Supported video modes | 2160p |
| HDCP | Yes |
| Plug and Play | Yes |
| Certification | Meets ROHS, FCC, and CE EMI requirements |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Maximum refresh rate | 60 Hz |
| HDCP version | 1.4/2.2 |
| Colour sampling | 4:2:0, 4:2:2 |
| USB version | 3.2 Gen 1 (3.1 Gen 1) |
| Cable colour | Black |
| Certificates | |
| Certification | Meets ROHS, FCC, and CE EMI requirements |
| Compliance certificates | RoHS |
| Technical details | |
| Country of origin | China |
| Cable colour | Black |
| Harmonized System (HS) code | 8544 4290 |
| Plastic packaging weight | 1 g |
| Compliance certificates | RoHS |
| Other features | |
| Width | 37 mm |
| Height | 180 mm |
| Depth | 15 mm |
| Cable colour | Black |
| Gross weight | 31 g |
| Packaging composition | |
| Plastic packaging weight | 1 g |
| Paper/cardboard packaging weight | 0 g |
| Total plastic packaging weight | 0 g |
| Total paper/cardboard packaging weight | 0 g |
| Weight & dimensions | |
| Width | 37 mm |
| Height | 180 mm |
| Depth | 15 mm |
| Weight | 21 g |
| Package width | 180 mm |
| Package depth | 110 mm |
| Package height | 18 mm |
| Package weight | 31 g |
| Packaging data | |
| Manual | Yes |
| Package width | 180 mm |
| Package depth | 110 mm |
| Package height | 18 mm |
| Package type | Polybag |
| Package weight | 31 g |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Manual | Yes |
| Quantity per pack | 1 pc(s) |
| Package type | Polybag |
| Logistics data | |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 8544 4290 |
