2 Mp, 0.095 Lux, 30fps, Micro SD, IP66, PoE, IK10, MJPEG, 1920 x 1080
0.095Lux (Color), 0Lux (B/W, IR LED on)
3.2 ~ 10mm (3.1x) varifocal lens
Max. 30fps@2M all resolutions (H.265/H.264)
H.265, H.264, MJPEG codec supported, Multiple streaming
Motion detection, Tampering, Defocus detection
Hallway view (90˚/270˚), LDC support
Micro SD/SDHC/SDXC memory slot (Max. 128GB)
IR viewable length 30m
IP66, IK10, PoE/12VDC
£288.75
Description
Max. 2megapixel (1920 x 1080) resolution0.095Lux (Color), 0Lux (B/W, IR LED on)
3.2 ~ 10mm (3.1x) varifocal lens
Max. 30fps@2M all resolutions (H.265/H.264)
H.265, H.264, MJPEG codec supported, Multiple streaming
Motion detection, Tampering, Defocus detection
Hallway view (90˚/270˚), LDC support
Micro SD/SDHC/SDXC memory slot (Max. 128GB)
IR viewable length 30m
IP66, IK10, PoE/12VDC
Specifications
| Performance | |
|---|---|
| Languages support | Simplified Chinese, Traditional Chinese, Czech, German, Dutch, English, Spanish, French, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Swedish, Turkish |
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Alarm input/output | Yes |
| Design | |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling |
| Protection features | Vandal proof |
| International Protection (IP) code | IP66 |
| Housing material | Aluminium |
| Camera | |
| Adjustment shutter speed | Manual |
| Minimum illumination | 0.095 lx |
| Tilt angle range | 0 - 67° |
| Pan range | 0 - 350° |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Camera shutter type | Electronic |
| Lens viewing angle, horizontal | 104.7° |
| Lens viewing angle, vertical | 76.5° |
| Lens viewing angle, diagonal | 136° |
| Progressive scan | Yes |
| Image sensor | |
| Number of effective pixels (H x V) | 1920 x 1080 pixels |
| Sensor type | CMOS |
| Progressive scan | Yes |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Lens system | |
| Maximum aperture number | 1.6 |
| Focal length range | 3.2 - 10 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 30 m |
| LED type | IR |
| Video | |
| Noise reduction | Yes |
| Privacy masking | Yes |
| Flip & mirror | Yes |
| Gain control type | Manual |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 1920 x 1080 pixels |
| Supported graphics resolutions | 640 x 360, 640 x 480 (VGA), 720 x 480, 720 x 576, 800 x 448, 800 x 600 (SVGA), 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
| Video streaming | Yes |
| Total megapixels | 2 MP |
| Audio | |
| Voice codecs | G.711, G.726 |
| Audio system | 1-way |
| Network | |
| Bluetooth | No |
| Ethernet interface type | 10 Gigabit Ethernet, 100 Gigabit Ethernet |
| Networking standards | IEEE 802.1x |
| Quality of Service (QoS) support | Yes |
| Number of users | 6 user(s) |
| Streaming method | Multicast, Unicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP |
| Storage | |
| Maximum memory card size | 128 GB |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Security | |
| Alert notification type | |
| Video motion detection | Yes |
| IP address filtering | Yes |
| Active tampering alarm | Yes |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 7.7 W |
| Power consumption (typical) | 6 W |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 55 °C |
| Storage temperature (T-T) | -30 - 60 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Storage relative humidity (H-H) | 0 - 90% |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Weight & dimensions | |
| Height | 106.1 mm |
| Diameter | 13.7 cm |
| Weight | 710 g |
| Packaging content | |
| Number of cameras | 1 |
| Other features | |
| Video compression formats | H.264, H.265, M-JPEG |
