65 W, USB-A, USB-C, 100-240 V, AC 50/60 Hz, 79 g
The charger offers a maximum total output power of 65 W. It has a USB-C port with Power Delivery (PD) 65 W and a USB-A port with Quick Charge (QC) 4.0. You can quickly charge a USB-A and a USB-C device at the same time. Wide compatibility including laptops, smartphones, tablets and more. Enhanced safety features such as over-current, over-voltage, over-temperature and short-circuit protection ensure extremely safe charging.
£21.25
Key Features
- USB-A (QC) 18 W and USB-C (PD) 65 W
- Ultra-slim design, only 1.4 cm thin
- GaN technology for a more compact design and better heat dissipation
- Input: 100-240 V AC 50/60 Hz 1.5A max
- Output: USB-C: 5,0 V/3,0 A (15,0 W). 9,0 V/3,0 A (27,0 W). 12,0 V/3,0 A (36,0 W). 15,0 V/3,0 A (45,0 W). 20,0 V/3,25 A (65,0 W max.) USB-A: 5,0 V/3,0 A (15,0 W). 9,0 V/2,0 A (18,0 W). 12,0 V/1,5 A (18,0 W max.) USBA+C: 12,0 W+ 45,0 W = 57,0 W Total: 65,0
- Average efficiency during operation: 81.28 %, efficiency at low load (10 %): 80.20 %; power consumption at no load: 0.08 W
- Device protection: Overcurrent, overvoltage, over-temperature, and short circuit protections
- Compatible with a wide range of devices, including laptops, smartphones and tablets
- Color: White
Description
The LogiLink USB-C GaN 65W Charger is an ultra-slim charger that has been specially developed for tight spaces. Thanks to the innovative GaN technology, it is physically smaller and dissipates higher voltages than silicon-based chargers, with better heat dissipation. At just 1.4 cm thick, it is ideal for travelling and narrow sockets.The charger offers a maximum total output power of 65 W. It has a USB-C port with Power Delivery (PD) 65 W and a USB-A port with Quick Charge (QC) 4.0. You can quickly charge a USB-A and a USB-C device at the same time. Wide compatibility including laptops, smartphones, tablets and more. Enhanced safety features such as over-current, over-voltage, over-temperature and short-circuit protection ensure extremely safe charging.
Specifications
| Performance | |
|---|---|
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| Power protection features | Over current, Over voltage, Overcharge, Overheating, Short circuit |
| Fast charging | Yes |
| Fast charging technology | Power Delivery 3.0, Quick Charge 4 |
| USB Type-C ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| Wireless charging | No |
| USB Power Delivery revision | 3.0 |
| USB Power Delivery up to | 65 W |
| Number of outputs | 2 outputs |
| Number of simultaneously connected devices (max) | 2 |
| USB Type-A ports quantity | 1 |
| Design | |
| Product colour | White |
| Gallium nitride (GaN) transistors | Yes |
| Power | |
| Input current | 1.5 A |
| Maximum power | 65 W |
| Input voltage | 100 - 240 V |
| Input frequency | 50 / 60 Hz |
| Maximum output voltage | 20 V |
| Minimum output voltage | 5 V |
| Output current (5V) | 3 A |
| Output current (9V) | 2 A |
| Output current (12V) | 1.5 A |
| Port 1 output power | 18 W |
| Port 2 output power | 65 W |
| Output current (15V) | 3 A |
| Output current (20V) | 3.25 A |
| Technical details | |
| Package type | Box |
| Charger type | Indoor |
| Charger compatibility | Universal |
| Power source type | AC |
| Power protection features | Over current, Over voltage, Overcharge, Overheating, Short circuit |
| AC adapter included | Yes |
| Manual | Yes |
| Weight & dimensions | |
| Width | 83 mm |
| Depth | 47 mm |
| Height | 52 mm |
| Weight | 79 g |
| Package width | 75 mm |
| Package depth | 50 mm |
| Package height | 95 mm |
| Package weight | 111 g |
| Packaging data | |
| Package type | Box |
| Package width | 75 mm |
| Package depth | 50 mm |
| Package height | 95 mm |
| Package weight | 111 g |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 40 °C |
| Packaging content | |
| Manual | Yes |
| Quantity per pack | 1 pc(s) |
| AC adapter included | Yes |
| Package type | Box |
| Colour | |
| Product colour | White |
| Other features | |
| Manual | Yes |
| Package type | Box |
| AC adapter included | Yes |
