1D/2D, 640x480 CMOS, LED, USB, 42°H/31.5°W
Snappy, even in less than perfect conditions
A combination of the IR sensor and the light sensor helps keep workers moving, even in low light conditions. Its strong, white light ensures barcodes are always well lit.
Handsfree or manual scanning
Companies looking for automatic scanning to relieve manual labor can set up the FM415 Bass for hands free scanning. Alternatively, a manual trigger button can be used if preferred.
Intelligent programming
The sensors of the FM415 Bass automatically adjust the brightness of supplementary lighting based on the light that reflects off the barcode. This also makes it an optimal solution for scanning from mobile phone screens. Depending on the application, the scanner can be set to optimally read from close and long distance.
Reliable outdoor use
With an IP rating of 54, this fixed mount scanner can be placed in a housing and used outdoors without worrying about dust or moisture.
£63.24
Key Features
- 1D & 2D
- IP54
- 1.5m drop
- USB
- RS232
- Infrared
- EasySet
- LED aimer
Description
The FM415 Bass is designed for fast, straightforward 2D scanning applications. With its intelligent programming, it can be set to read optimally from both close and long distances. Additionally, its power efficiency reduces power consumption and prolongs service life. This stationary scanner is ideal for smoothly transitioning from 1D to 2D scanning without increasing the budget.Snappy, even in less than perfect conditions
A combination of the IR sensor and the light sensor helps keep workers moving, even in low light conditions. Its strong, white light ensures barcodes are always well lit.
Handsfree or manual scanning
Companies looking for automatic scanning to relieve manual labor can set up the FM415 Bass for hands free scanning. Alternatively, a manual trigger button can be used if preferred.
Intelligent programming
The sensors of the FM415 Bass automatically adjust the brightness of supplementary lighting based on the light that reflects off the barcode. This also makes it an optimal solution for scanning from mobile phone screens. Depending on the application, the scanner can be set to optimally read from close and long distance.
Reliable outdoor use
With an IP rating of 54, this fixed mount scanner can be placed in a housing and used outdoors without worrying about dust or moisture.
Specifications
| Scanning | |
|---|---|
| Type | Barcode module bar code reader |
| Linear (1D) barcodes supported | AIM-128, Codabar, Code 11, Code 128, Code 39, Code 93, EAN 128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Expanded, GS1 Databar Limited, GS1 Databar RSS14, GS1-128 (UCC/EAN-128), ISBN, ISSN, ITF-14, ITF-6, Industrial 25, Interleaved 2 of 5, MSI-Plessey, Matrix 2 of 5, Plessey, Standard 25, UPC-A, UPC-E |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Data Matrix, MaxiCode, Micro QR Code, MicroPDF417, PDF417 |
| Yaw reading angle | -60 - 60° |
| Sensor type | CMOS |
| Scanner type | 1D/2D |
| Pitch reading angle | -60 - 60° |
| Optical sensor resolution (W x H) | 640 x 480 pixels |
| Horizontal field of view | 42° |
| Vertical field of view | 31.5° |
| Ports & interfaces | |
| Connectivity technology | Wired |
| USB 2.0 ports quantity | 1 |
| Standard interfaces | RS-232, USB |
| Performance | |
| Protection features | Drop resistant |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Buzzer | Yes |
| Print contrast | 25% |
| Design | |
| Type | Barcode module bar code reader |
| Protection features | Drop resistant |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Power | |
| Power consumption | 228 mA |
| Power source type | USB |
| Weight & dimensions | |
| Width | 49 mm |
| Depth | 69 mm |
| Height | 20 mm |
| Weight | 64.6 g |
| Technical details | |
| Type | Barcode module bar code reader |
| Protection features | Drop resistant |
| USB 2.0 ports quantity | 1 |
| International Protection (IP) code | IP54 |
| Product colour | Black |
| Buzzer | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Operational conditions | |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Drop resistance | 1.5 m |
| Other features | |
| USB 2.0 ports quantity | 1 |
