Print high quality, continuous labels using media up to 118mm/4.65 inch wide. With built-in network for easy sharing.
£425.54
Key Features
- Network connectivity
- Professional quality up to 300dpi print resolution
- Fast print speeds up to 6 inches per second
- Print width up to 4.27 inches / 108mm
- Easy set-up with automatic media configuration
- Ready to integrate with iOS and Android apps
Description
Using direct thermal print technology, accurate images with crisp definition is created. Great for printing high-volume, temporary labels with barcodes. The length of media is automatically calculated with the media calibration function. Removing the need of manually entering label dimensions. With network connectivity, data is quickly shared with different departments. Make the TD-4520DN bespoke to your needs with a range of accessories including a peeler and cutter.Specifications
| Print quality | |
|---|---|
| Maximum resolution | 300 x 300 DPI |
| Printing | |
| Date & time printing | Yes |
| Minimum print length | 1.7 cm |
| Text style | Bold, Horizontal lines, Invert, Italic, Normal, Shadow, Shadow light, Surround |
| Colour | No |
| Print speed | 6 lpm |
| Print speed | 203 mm/sec |
| Maximum resolution | 300 x 300 DPI |
| Print technology | Direct thermal |
| Mirror printing | Yes |
| Maximum print length | 3 m |
| Design | |
| LED indicators | Error, Power, Status |
| Display | No |
| Product colour | Grey, White |
| Built-in display | No |
| Display | |
| Display | No |
| Network | |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Memory | |
| Internal memory | 256 MB |
| Flash memory | 64 MB |
| Paper handling | |
| Maximum roll diameter | 12.7 cm |
| Maximum label width | 11.8 cm |
| Core diameter | 1.27 cm |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| RS-232 ports | 1 |
| Connectivity technology | Wired |
| Bluetooth | No |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| USB port | Yes |
| Performance | |
| Mobile operating systems supported | Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3 |
| Languages support | Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish |
| Number of languages | 18 |
| Built-in barcodes | CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E |
| Number of fonts | 6 |
| Internal memory | 256 MB |
| Flash memory | 64 MB |
| Page description languages | CPCL-native, DPL, EPL2, ESC P, Raster_P, ZPL II |
| Font styles | Brougham,Brussels,Helsinki,Letter Gothic,San Diego |
| Power | |
| Auto power off | Yes |
| Technical details | |
| Server operating systems supported | Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Warranty card | Yes |
| Product colour | Grey, White |
| Built-in barcodes | CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, EAN13, EAN8, GS1 DataBar, ITF, POSTNET, UPC-A, UPC-E |
| Number of fonts | 6 |
| Networking features | 10/100BASE-TX |
| Maximum label width | 11.8 cm |
| LED indicators | Error, Power, Status |
| Country of origin | China |
| Products per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Mirror printing | Yes |
| Font styles | Brougham,Brussels,Helsinki,Letter Gothic,San Diego |
| Harmonized System (HS) code | 84433210 |
| Pallet type | 800 x 1200 mm |
| System requirements | |
| Mobile operating systems supported | Android 4.1, Android 4.2, Android 4.2.1, Android 4.2.2, Android 4.3, Android 4.4, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 12, iOS 8.0, iOS 8.1, iOS 8.2, iOS 8.3, iOS 8.4, iOS 9.0, iOS 9.1, iOS 9.2, iOS 9.3 |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2008, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows 8.1 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 20 - 85% |
| Operating temperature (T-T) | 10 - 90 °C |
| Operating relative humidity (H-H) | 5 - 40% |
| Weight & dimensions | |
| Width | 265 mm |
| Depth | 335 mm |
| Height | 258 mm |
| Weight | 3.04 kg |
| Package weight | 3.96 kg |
| Packaging data | |
| Package weight | 3.96 kg |
| Quantity per pack | 1 pc(s) |
| Packaging content | |
| Software development kit (SDK) | Yes |
| AC adapter included | Yes |
| Warranty card | Yes |
| Quick start guide | Yes |
| Cables included | AC, USB |
| Starter roll included | Yes |
| Quantity per pack | 1 pc(s) |
| Other features | |
| Products per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Quantity per pack | 1 pc(s) |
| Date & time printing | Yes |
| Languages support | Simplified Chinese, Czech, Danish, German, Dutch, English, Spanish, Finnish, French, Hungarian, Italian, Japanese, Norwegian, Polish, Portuguese, Russian, Swedish, Turkish |
| Number of languages | 18 |
| Networking features | 10/100BASE-TX |
| LED indicators | Error, Power, Status |
| Country of origin | China |
| Logistics data | |
| Pallet gross height | 14.4 cm |
| Master (outer) cases per pallet layer | 8 pc(s) |
| Pallet gross weight | 176.4 kg |
| Products per pallet | 40 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 40 pc(s) |
| Harmonized System (HS) code | 84433210 |
