12MP AI Fisheye Camera, 1/1.6" 12MP CMOS, Day & Night (ICR), WDR (120dB), WiseNRⅡ (Using AI engine), IP66, IK10, NEMA4X
£701.25
Key Features
- 1/1.6" 12MP CMOS
- 1.76mm fixed stereo graphic type lens
- Colour: 0.02Lux(F1.8, 1/30sec), BW: 0.001Lux(F1.8, 1/30sec)
- Digital Rotation
- Resolution/Framerate - Original view: Max. 20fps@3008x3008 - Double panorama: Max. 20fps@3584x1792 - Single panorama: Max. 20fps@3584x896 - Quad view: Max. 20fps@3584x2688 - Q1/Q2/Q3/Q4(4:3): Max. 20fps@1792x1344
- Day & Night (ICR), WDR (120dB), WiseNRⅡ (Using AI engine)
- H.265, H.264, MJPEG, WiseStreamⅢ (Using AI engine)
- Analytics events based on AI engine - Object detection (Person/Vehicle) - Colour Attribute, BestShot - Motion detection, Virtual line (Crossing/Direction), Virtual area (Loitering/Intrusion/Enter/Exit)
- IP66, IK10, NEMA4X
Description
Specifications
| Performance | |
|---|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Design | |
| IK code | IK10 |
| Form factor | Dome |
| Product colour | White |
| Mounting type | Ceiling |
| International Protection (IP) code | IP66 |
| Housing material | Plastic |
| Camera | |
| Minimum illumination | 0.001 lx |
| Camera shutter type | Electronic |
| Camera shutter speed | 1/30 s |
| Lens viewing angle, horizontal | 185° |
| Lens viewing angle, vertical | 185° |
| Lens viewing angle, diagonal | 185° |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 1.6 mm (1 / 1.6") |
| Number of sensors | 1 |
| Lens system | |
| Maximum aperture number | 1.8 |
| Closest focusing distance | 0.5 m |
| Zoom capability | Yes |
| Fixed focal length | 1.76 mm |
| Video | |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | WiseNR Ⅱ |
| Video compression formats | H.264, H.265, M-JPEG |
| Maximum resolution | 3008 x 3008 pixels |
| Frame rate | 20 fps |
| Total megapixels | 12 MP |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Ethernet LAN | No |
| Wi-Fi | No |
| Storage | |
| Built-in HDD | No |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Security | |
| Video motion detection | Yes |
| Management features | |
| Cloud-managed | No |
| Power | |
| Power source type | AC |
| Weight & dimensions | |
| Length | 75.7 mm |
| Diameter | 12 cm |
| Packaging content | |
| Number of cameras | 1 |
| Other features | |
| Video compression formats | H.264, H.265, M-JPEG |
