1/2.8” CMOS, Max Resolution 2592x1944@30FPS, 0.04Lux@F1.3 (Color), 0Lux (B/W IR LED On), 3.3~9.3mm (2.8x), 160 x 188 mm, 1210 g
Powering the next generation.
Hanwha Vision X series cameras come equipped with Wisenet 9, built with a dual NPU architecture to execute advanced AI analytics models and image optimization for exceptional performance.
See the details that matter.
Leverage advanced license-free AI analytics with intelligent attribute extraction and expandable AI analytics packs tailored for any industry.
More insight
Gain deeper insights with advanced AI object detection with attribute extraction.
License-free edge analytics
Utilize AI-based video analytics for increased efficiency and custom notifications to maximize the performance of your security system.
Business intelligence
Gain valuable insights with built-in analytics for business intelligence.
Robust rules engine
Trigger recording, alerts, notifications and more using license-free analytics. Combine up to 3 event conditions to create custom triggers to maximize system efficiency.
Dynamic privacy masking
Wisenet 9-enabled cameras use dynamic privacy masking (DPM) to protect sensitive objects, such as people, faces, vehicles and license plates, ensuring compliance with privacy regulations without compromising security.
Customize your intelligence
Access versatile AI packs – pre-built solutions for retail, traffic, banking, manufacturing, and more to enhance your security system.
Browse AI Packs
Optimized image quality. Reduced bandwidth.
The Hanwha Vision X series Gen 2 cameras use advanced image processing and AI-driven enhancements to minimize noise and maximize detail while lowering bandwidth and storage.
Smart noise reduction
Using AI object detection, X series Gen 2 cameras reduce noise and motion blur to produce clear images, especially in low and challenging lighting conditions.
Optimized bandwidth efficiency
Combining H.265 encoding, AI-based noise reduction and AI-based WiseStream compression, Wisenet 9-equipped devices offer unprecedented bandwidth reduction without compromising video quality.
Automated exposure adjustment
Multi-frame eXtreme WDR (Wide Dynamic Range) technology optimizes tone and contrast to improve the detail and clarity of images in adverse lighting conditions.
Connect and configurevia Wi-Fi
Easily connect to your X series Gen 2 cameras with a Wi-Fi dongle and use the Wisenet Installation app to adjust camera positioning, zoom, focus, and viewing angles.*
*Wisenet Installation app can be downloaded from the app store (Wi-Fi dongle and USB-c type cable not included).
Cloud-connected and VMS compatible.
Cloud-connected and VMS compatible. X series camera models are natively supported by Hanwha Vision’s Cloud Portal applications - enabling easier integration, remote device management, and access.
Direct-to-cloud recording and real-time analytics reporting out of the box
Access OnCloud for live and recorded video, searchable clips, event notifications, and more… on any device.
Real-time analytics reporting
Use SightMind to maximize safety, efficiency and insights with custom dashboards for analytics on security and business intelligence.
Remote device monitoring
Monitor and manage usage data of CPU and RAM in real-time. Optimize power consumption through Wisepower and use HealthPro to check on the health of each device.
VMS compatibility
Seamlessly integrate with popular VMS platforms, including Wisenet WAVE, Milestone and Genetec.
£803.75
Key Features
- Handover
- Dynamic Privacy Mask
- AI Engine Based Analytics: Motion & Object Detection, Line Crossing, IVA Area, Slip & Fall, Sound Classification
- Object Detection: Person/Face/Vehicle/License Plate
- Object Attributes: Person (Gender, Top/Bottom Clothing Color, Bag), Face (Age, Gender, Mask, Glasses), Vehicle (Type, Color)
- BestShot
- Analytics Events: Defocus, Motion, Tampering, Fog, Audio & Shock Detection
- AI Based Business Intelligence: People/Vehicle/Crowd Counting, Queue Management, Heatmap
- IP66/IP67, IK10, NEMA 4X, NEMA-TS 2(2.2.7.2-8, 2.2.8, 2.2.9)
- Operating Temp: -40°C~+50°C (-40°F~+122°F)
- Built-In MicroSD Card Slot (x1) (Up to 1TB)
- PoE
- Metal shielded RJ-45 (10/100BASE-T)
Description
Hanwha Vision X series Gen 2 cameras bring the power of advanced AI to the edge, enabling smarter, faster and more reliable security. Designed for today’s dynamic environments, X series Gen 2 cameras help organizations see, know and do more with every frame.Powering the next generation.
Hanwha Vision X series cameras come equipped with Wisenet 9, built with a dual NPU architecture to execute advanced AI analytics models and image optimization for exceptional performance.
See the details that matter.
Leverage advanced license-free AI analytics with intelligent attribute extraction and expandable AI analytics packs tailored for any industry.
More insight
Gain deeper insights with advanced AI object detection with attribute extraction.
License-free edge analytics
Utilize AI-based video analytics for increased efficiency and custom notifications to maximize the performance of your security system.
Business intelligence
Gain valuable insights with built-in analytics for business intelligence.
Robust rules engine
Trigger recording, alerts, notifications and more using license-free analytics. Combine up to 3 event conditions to create custom triggers to maximize system efficiency.
Dynamic privacy masking
Wisenet 9-enabled cameras use dynamic privacy masking (DPM) to protect sensitive objects, such as people, faces, vehicles and license plates, ensuring compliance with privacy regulations without compromising security.
Customize your intelligence
Access versatile AI packs – pre-built solutions for retail, traffic, banking, manufacturing, and more to enhance your security system.
Browse AI Packs
Optimized image quality. Reduced bandwidth.
The Hanwha Vision X series Gen 2 cameras use advanced image processing and AI-driven enhancements to minimize noise and maximize detail while lowering bandwidth and storage.
Smart noise reduction
Using AI object detection, X series Gen 2 cameras reduce noise and motion blur to produce clear images, especially in low and challenging lighting conditions.
Optimized bandwidth efficiency
Combining H.265 encoding, AI-based noise reduction and AI-based WiseStream compression, Wisenet 9-equipped devices offer unprecedented bandwidth reduction without compromising video quality.
Automated exposure adjustment
Multi-frame eXtreme WDR (Wide Dynamic Range) technology optimizes tone and contrast to improve the detail and clarity of images in adverse lighting conditions.
Connect and configurevia Wi-Fi
Easily connect to your X series Gen 2 cameras with a Wi-Fi dongle and use the Wisenet Installation app to adjust camera positioning, zoom, focus, and viewing angles.*
*Wisenet Installation app can be downloaded from the app store (Wi-Fi dongle and USB-c type cable not included).
Cloud-connected and VMS compatible.
Cloud-connected and VMS compatible. X series camera models are natively supported by Hanwha Vision’s Cloud Portal applications - enabling easier integration, remote device management, and access.
Direct-to-cloud recording and real-time analytics reporting out of the box
Access OnCloud for live and recorded video, searchable clips, event notifications, and more… on any device.
Real-time analytics reporting
Use SightMind to maximize safety, efficiency and insights with custom dashboards for analytics on security and business intelligence.
Remote device monitoring
Monitor and manage usage data of CPU and RAM in real-time. Optimize power consumption through Wisepower and use HealthPro to check on the health of each device.
VMS compatibility
Seamlessly integrate with popular VMS platforms, including Wisenet WAVE, Milestone and Genetec.
Specifications
| Performance | |
|---|---|
| Type | IP security camera |
| Connectivity technology | Wired |
| Placement supported | Indoor & outdoor |
| Wide Dynamic Range (WDR) | Yes |
| Dynamic range | 120 dB |
| Design | |
| IK code | IK10 |
| Form factor | Bullet |
| Product colour | White |
| Mounting type | Ceiling/wall |
| International Protection (IP) code | IP66, IP67 |
| Housing material | Aluminium, Polycarbonate (PC) |
| Camera | |
| Tilt angle range | 0 - 90° |
| Pan range | 0 - 350° |
| White balance | ATW, AWC, Indoor, Manual, Outdoor |
| Angle of rotation | 350° |
| Camera shutter type | Electronic |
| Camera shutter speed | 2~1/30,000 s |
| Lens viewing angle, horizontal | 99 - 31° |
| Lens viewing angle, vertical | 71 - 23° |
| Lens viewing angle, diagonal | 133 - 39° |
| Number of Privacy masking areas | 32 |
| Image sensor | |
| Sensor type | CMOS |
| Optical sensor size | 25.4 / 2.8 mm (1 / 2.8") |
| Lens system | |
| Maximum aperture number | 1.6 |
| Recognize distance (wide) | 8.7 m |
| Recognize distance (tele) | 36.9 m |
| Observe distance (wide) | 17.5 m |
| Observe distance (tele) | 73.8 m |
| Identify distance (wide) | 4.4 m |
| Identify distance (tele) | 18.5 m |
| Detect distance (wide) | 43.7 m |
| Detect distance (tele) | 184.6 m |
| Zoom capability | Yes |
| Optical zoom | 2.8x |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 50 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video | |
| Noise reduction | Yes |
| Highlight Compensation (HLC) | Yes |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR), Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Noise reduction technology | Smart Super Noise Reduction V (SSNR V), WiseNR Ⅱ |
| Maximum resolution | 2560 x 1920 pixels |
| Video formats supported | H.264, H.265, M-JPEG |
| Frame rate | 30 fps |
| Total megapixels | 5 MP |
| Network | |
| Bluetooth | No |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3af |
| Number of users | 20 user(s) |
| Streaming method | Multicast, Unicast |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Supported network protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP/SFTP, SMTP(StartTLS), ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast), CDP, MQTT, Syslog |
| Storage | |
| Maximum memory card size | 1 TB |
| Card reader integrated | Yes |
| Built-in HDD | No |
| Compatible memory cards | MicroSD (TransFlash), SDHC, SDXC |
| eMMC capacity | 8 TB |
| RAM capacity | 4000 MB |
| Ports & interfaces | |
| USB port | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Connectivity technology | Wired |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 9.4 W |
| Power consumption (typical) | 7 W |
| Operational conditions | |
| Operating temperature (T-T) | -40 - 60 °C |
| Storage temperature (T-T) | -50 - 60 °C |
| Operating relative humidity (H-H) | 0 - 100% |
| Storage relative humidity (H-H) | 0 - 90% |
| Weight & dimensions | |
| Height | 160 mm |
| Diameter | 11.8 cm |
| Weight | 1.21 kg |
| Packaging content | |
| Number of cameras | 1 |
